Masonry Row Grid Layout

{
	"registries": {
		"@nexul": "https://ui.nexul.in/r/{name}.json"
	}
}

import { clsx, type ClassValue } from "clsx"
import { twMerge } from "tailwind-merge"

export function cn(...inputs: ClassValue[]) {
  return twMerge(clsx(inputs))
}

import type * as React from 'react';

export function mergeRefs<T>(
  ...refs: (React.Ref<T> | undefined)[]
): React.RefCallback<T> {
  return (value) => {
    refs.forEach((ref) => {
      if (typeof ref === 'function') {
        ref(value);
      } else if (ref) {
        ref.current = value;
      }
    });
  };
}

"use client";

import { cn } from "@/lib/utils";
import React from "react";
import {
  calculateJustifiedMasonryLayout,
  calculateNaiveMasonryLayout,
} from "./calculate-masonry-row";
import { mergeRefs } from "@/lib/merge-refs";

export type GridItemProps = {
  /* Original width of the grid item */
  width: number;
  /* Original height of the grid item */
  height: number;

  // Additional properties can be added as needed
  // eslint-disable-next-line @typescript-eslint/no-explicit-any
  [key: string]: any;
};

export type Measures = {
  /* Calculated width of the grid item */
  width: number;
  /* Calculated height of the grid item */
  height: number;
  /* Calculated top position of the grid item */
  top: number;
  /* Calculated left position of the grid item */
  left: number;

  /* Row number of the grid item in the row (0-based index) */
  index: number;
  /* Row number of the grid item (1-based index) */
  rowNo: number;
  /* Total items in the row */
  totalItemsInRow: number;
};

type Props = {
  /** Container props for the masonry grid container */
  containerProps?: React.HTMLAttributes<HTMLDivElement>;
  /** Item props for each masonry grid item */
  itemProps?: React.HTMLAttributes<HTMLDivElement>;
  /** Gap between grid items */
  gap?: number;
  /** Target height for each grid item; default is 300 */
  targetHeight?: number;
  /** Scale factor for resizing grid items; default is 0.1 */
  scaleFactor?: number;
  /** Layout type: "naive" or "justified"; default is "naive" */
  layout?: "naive" | "justified";
  /** Array of grid items to be displayed */
  items?: GridItemProps[];
  /** Function to render each grid item */
  renderItem?: (
    /** Props of the grid item to be rendered */
    item: GridItemProps,
    /** Index of the grid item in the array */
    index: number,
    /** Calculated measures for the grid item */
    measures: Measures
  ) => React.ReactNode;
};

const MasonryRowGrid = React.forwardRef<HTMLDivElement, Props>(
  (
    {
      containerProps: { className, ...containerProps } = {},
      itemProps: {
        className: itemClassName,
        style: itemStyle,
        ...itemProps
      } = {},
      gap = 8,
      targetHeight = 300,
      scaleFactor = 0.1,
      layout: layoutType = "naive",
      items = [],
      renderItem,
    }: Props,
    ref
  ) => {
    const [viewportWidth, setViewportWidth] = React.useState<number>(0);
    const containerRef = React.useRef<HTMLDivElement | null>(null);

    const layout = React.useMemo(
      () =>
        layoutType === "naive"
          ? calculateNaiveMasonryLayout({
              viewportWidth,
              items,
              targetHeight,
              scaleFactor,
            })
          : calculateJustifiedMasonryLayout({
              viewportWidth,
              items,
              targetHeight,
              scaleFactor,
            }),
      [layoutType, viewportWidth, items, targetHeight, scaleFactor]
    );

    React.useLayoutEffect(() => {
      if (!containerRef.current || containerRef.current === null) return; // Return if the container is not found
      let animationFrameID: number | null = null; // Initialize animation frame ID

      const resizeObserver = new ResizeObserver((entries) => {
        const newWidth = entries[0].contentRect.width; // This gives the actual width of the inside of the container
        if (animationFrameID) cancelAnimationFrame(animationFrameID); // Cancel the previous animation frame

        animationFrameID = requestAnimationFrame(() => {
          setViewportWidth(newWidth); // Update the viewport width based on the resize observer
        });
      });
      resizeObserver.observe(containerRef.current); // Observe the container for changes
      return () => {
        resizeObserver.disconnect(); // Cleanup the observer on unmount
        if (animationFrameID) cancelAnimationFrame(animationFrameID); // Cancel the animation frame on unmount
      };
    }, [containerRef, gap, items, targetHeight, scaleFactor]);

    return (
      <div
        ref={mergeRefs(containerRef, ref)}
        className={cn("relative w-full flex flex-wrap", className)}
        {...containerProps}
      >
        {items.map((item, index) => {
          const measures = layout[0][index];

          return (
            <div
              key={index}
              className={cn("absolute", itemClassName)}
              style={{
                top: measures.top,
                left: measures.left,
                width: measures.width,
                height: measures.height,

                paddingTop: measures.rowNo === 1 ? gap : gap / 2,
                paddingBottom: measures.rowNo === layout[2] ? gap : gap / 2,
                paddingLeft: measures.index === 0 ? gap : gap / 2,
                paddingRight:
                  measures.index === measures.totalItemsInRow - 1
                    ? gap
                    : gap / 2,

                ...itemStyle,
              }}
              {...itemProps}
            >
              {renderItem ? renderItem(item, index, measures) : null}
            </div>
          );
        })}
      </div>
    );
  }
);
MasonryRowGrid.displayName = "MasonryRowGrid";

export { MasonryRowGrid };

import { GridItemProps, Measures } from "./masonry-row";

/**
 * Calculates the masonry layout for a set of items within a given viewport width.
 * @param viewportWidth - The width of the container in which the items will be laid out.
 * @param items - An array of items to be laid out, each with width and height properties.
 * @param targetHeight - The desired height for each row in the layout.
 * @param scaleFactor - A factor to allow rows to deviate from the target height.
 *
 * @returns [Measures[], totalHeight, rowCount]
 */
export function calculateNaiveMasonryLayout({
  viewportWidth,
  items,
  targetHeight,
  scaleFactor = 0.1,
}: {
  viewportWidth: number;
  items: GridItemProps[];
  targetHeight: number;
  scaleFactor?: number;
}) {

  const max_height = targetHeight * (1 + scaleFactor);

  let rows: Measures[] = [];
  let row: Measures[] = [];
  let currentWidth = 0;
  let totalHeight = 0; // Initialize total height
  let rowNumber = 1; // Initialize row number

  function finalizeRow() {
    // Calculate the height of the row based on the width and max height
    const height =
      viewportWidth < currentWidth
        ? (viewportWidth / currentWidth) * max_height
        : max_height;

    let left = 0;
    for (let i = 0; i < row.length; i++) {
      const item = row[i];
      const width = (height / item.height) * item.width;

      row[i].width = width;
      row[i].height = height;
      row[i].top = totalHeight;
      row[i].left = left;

      row[i].index = i; // Update index in the row
      row[i].totalItemsInRow = row.length; // Update total images in the row
      left += width;
    }

    rows = rows.concat(row);
    totalHeight += height;
    row = [];
    currentWidth = 0;
    rowNumber += 1; // Increment row number
  }

  items.forEach((item) => {
    row.push({
      width: item.width,
      height: item.height,
      top: 0,
      left: 0,

      index: 0, // Placeholder, will be updated while finalizing
      rowNo: rowNumber,
      totalItemsInRow: 0, // Placeholder, will be updated while finalizing
    });
    currentWidth += (max_height / item.height) * item.width;

    // If current width exceeds viewport, finalize the row
    if (currentWidth >= viewportWidth) finalizeRow();
  });

  if (row.length > 0) finalizeRow();

  return [rows, totalHeight, rowNumber] as const;
}

/**
 * Calculates the masonry layout for a set of items within a given viewport width.
 * @param viewportWidth - The width of the container in which the items will be laid out.
 * @param items - An array of items to be laid out, each with width and height properties.
 * @param targetHeight - The desired height for each row in the layout.
 * @param scaleFactor - A factor to allow rows to deviate from the target height.
 *
 * @returns [Measures[], totalHeight, rowCount]
 */
export function calculateJustifiedMasonryLayout({
  viewportWidth,
  items,
  targetHeight,
  scaleFactor = 0.1,
}: {
  viewportWidth: number;
  items: GridItemProps[];
  targetHeight: number;
  scaleFactor?: number;
}): [Measures[], number, number] {
  const min_height = targetHeight * (1 - scaleFactor);
  // const max_height = targetHeight * (1 + scaleFactor);
  // const MAX_TOLERANCE = targetHeight * 1.35;

  const count = items.length;
  const aspectRatios = items.map((item) => item.width / item.height);

  // dp[i] represents the minimum cost to arrange items[0..i-1]
  const dp = new Array(count + 1).fill(Infinity);
  dp[0] = 0;

  // parent[i] stores the starting index of the row that ends at i
  // This is used to reconstruct the layout later
  const parent = new Array(count + 1).fill(0);

  for (let i = 1; i <= count; i++) {
    let currentAspectRatioSum = 0;

    // Look back at previous items to find the best break point
    for (let j = i - 1; j >= 0; j--) {
      currentAspectRatioSum += aspectRatios[j];
      const rowHeight = viewportWidth / currentAspectRatioSum;

      // As we add more items (decreasing j), the rowHeight gets smaller.
      // If it's already smaller than min_height, adding more items will only
      // make it worse (shorter). So we can stop looking back.
      if (rowHeight < min_height) {
        // However! If this is the very first item we are checking (j === i-1),
        // we must accept it, otherwise we might end up with NO valid path
        // if a single panorama is naturally shorter than min_height.
        if (j !== i - 1) break;
      }

      // If a row is too tall, the squared cost will naturally be high,
      // but it will still be selectable if it's the only option.
      let cost = Math.pow(rowHeight - targetHeight, 2);

      // Orphan Penalty
      // We generally dislike rows with only 1 item, unless that item is naturally wide.
      // If the row has 1 item and it's making the row tall (> target), add a penalty.
      if (i - j === 1 && rowHeight > targetHeight)
        cost += Math.pow(targetHeight, 2) * 2;

      // Total cost if we break the row here
      // This includes the cost up to the previous item plus the cost of the current row
      const totalCost = dp[j] + cost;

      // Update dp and parent if we found a new minimum cost
      if (totalCost < dp[i]) {
        dp[i] = totalCost;
        parent[i] = j;
      }
    }

    // Fallback for safety against Infinity
    if (dp[i] === Infinity) {
      parent[i] = i - 1;
      dp[i] = dp[i - 1] + Math.pow(targetHeight * 10, 2);
    }
  }

  const measures: Measures[] = new Array(count);
  const rows: { start: number; end: number; height: number }[] = [];

  // Backtrack from the last item to finding row breaks
  let curr = count;
  while (curr > 0) {
    const start = parent[curr];

    // Recalculate the exact height for this final decided row
    let rowAspectRatioSum = 0;
    for (let k = start; k < curr; k++) rowAspectRatioSum += aspectRatios[k];

    const exactRowHeight = viewportWidth / rowAspectRatioSum;
    // if (exactRowHeight > MAX_TOLERANCE) exactRowHeight = MAX_TOLERANCE;

    rows.unshift({ start, end: curr, height: exactRowHeight });
    curr = start;
  }

  // Generate Measures
  let currentTop = 0;

  rows.forEach((row, rowIndex) => {
    let currentLeft = 0;
    const itemsInRow = row.end - row.start;

    for (let k = row.start; k < row.end; k++) {
      const itemWidth = aspectRatios[k] * row.height;

      measures[k] = {
        width: itemWidth,
        height: row.height,
        top: currentTop,
        left: currentLeft,
        index: k - row.start,
        rowNo: rowIndex + 1,
        totalItemsInRow: itemsInRow,
      };

      currentLeft += itemWidth;
    }

    currentTop += row.height;
  });

  return [measures, currentTop, rows.length];
}
